Operation

Technical data & incubation reference

Specifications

Technical data, dimensions & power

Setter — 60,000 Egg Capacity

Length216 in (18 ft)

Breadth96 in (8 ft)

Height7.4 in

Heaters500W × 6 = 3000W

Fan motor1/3 HP (252W × 2 = 504W)

Turning motor1/2 HP (0.37 kW)

Total power6 HP (4.9 kW)

Voltage220V AC, 1‑phase, 50Hz

Hatcher — 10,400 Egg Capacity

Length2.08 m

Breadth2.08 m

Height2.08 m

Heaters400W × 4 = 1600W

Fan motor1/3 HP (0.25 kW)

Total power3 HP (2.25 kW)

Voltage220V AC, 1‑phase, 50Hz

Reference Table

Species	Incubation Period	Temp (°F)	Humidity	Transfer Day	Humidity, Last 3 Days
Chicken	21 days	99.9	85–87	18th day	90
Turkey	28 days	99.9	84–86	25th day	90
Goose	34 days	99	86–88	25th day	90
Guinea Fowl	28 days	100	85–87	25th day	90
Pheasant	28 days	100	85–87	25th day	92
Peafowl	30 days	99	84–86	25th day	90
Bobwhite Quail	24 days	100	84–87	20th day	90
Japan Quail	17 days	100	85–86	15th day	90
Chukar	24 days	100	81–83	20th day	90
Grouse	25 days	100	83–87	22nd day	90
Golden Pigeon	17 days	100	85–87	15th day	90
Duck	28 days	100	85–86	25th day	99.9

Reference

Full specifications for every incubator, hatcher and spare part we manufacture.
